Pintech TEH-10030(Button version) 30kV Electrostatic discharge generator (Button version, 0.1～30.0kV±5%)

Output voltage: 0.1～30.0kV±5%

Signal source: BMM

Output voltage polarity: +/-/±

Resistance capacitance kit: 330Ω/150pF

Follow the standard: IEC61000-4-2, GB/T17626.2

Trigger mode: Single/continuous/20 times/second

Control mode: Gun control/ Mainframed

Discharge mode: Contact/air

Output times: 1～9999 times

Output interval: 0.05s～9.99s

Discharge current rise time: 0.6-1ns

Static holding time: >5s

Display: LED

Power supply: AC 220V±10%,50/60Hz

Size: 415*300*170mm

Weight: 7.3kg

Accessories detail: power cord, electrostatic gun, conical tip, round tip
