DC Output:
Voltage: 0-30V
Current: 0-10A
Power: 300W
Ripple: ≤0.5%FS+10mVrms
Load regulation: ≤0.5%
Input
Phase: 1φ2W
Voltage: 220V±10%
Frequency: 50Hz±10%
Circuit Mode: PWM
Accuracy: ±1%rdg ± 2digit(10%-100% rated value)
Voltage resolution: 5 digits 0.001V
Current resolution: 5 digits 0.001A
Power resolution: 5 digits 0.01W
Programmable groups: 32 sets
Programmable rise time: 0.1-99.9S
Programmable operating time: 0.1-99999S
Recyclable times: 99999
Insulation: Input to the chassis :20MΩ 500V DC,Output to the chassis : 20MΩ 500V DC
Pressure resistance: Input to the chassis :1500V AC 1 minute;Input to output :1500V AC 1minute.
Memory: RS232 MODBUS RTU
Protection: Over voltage, over current, over temperature, short circuit, reverse
Environment: 0-40℃ 10%-90%(No condensation)
Weight :20Kg
Size(mm): 430*88*450mm
