Output Voltage( DC Max): 400V DC
Output Voltage(AC Max): 800Vp-p
DC Current(Max): 35mA
AC Current(Max): 70mAp-p
Output Power(Max): 14VA
Frequency response (Bandwidth): 200kHz/400Vp-p
Slew Rate: 200V/μs
Output impedance: 100Ω
Protect resistor: 15kΩ/40watt
Safe Loading: ≧11kΩ/800Vp-p
Input Voltage upper limit: 0~10Vp-p/20Vp-p
AMPL: 0~180 (10 turn knob)
OFFEST: 0 or± 400V (10-turnknob switch)
Monitor: 100:1
Output protection:
1. Output dedicated FUSE
2. Protection SW (switch)
Weight: 5.2kg
size: 310*270*95mm
