Bandwidth(-3dB): DC-65MHz
Rise time: 5.4ns
Attenuation Ratio: 20X,50X,200X
Accuracy: ±2% (20 minutes after the warm-up)
Testing Vp-p: 160V-400V-1600V
Input DC Voltage: 80V-200V-800V
AC rms: 560Vrms
Tiếng ồn: ≤0.7mV rms
CMRR (Typical): 60Hz:＞80dB；100Hz:＞60dB;1MHz:＞50dB
Input impedance: 4MΩ//1.2pF
Oscilloscope input impedance: 1MΩ
Power: 9V adapter
Max. consumption: 35mA
Temperature and Humidity: 0~50℃ and 10~85%RH
Dimension (LxWxH) mm: 195x55x30
Weight: 250g
