Bandwidth (–3 dB): 200 MHz
Input type: Single-ended, BNC connector
Maximum equivalent sampling rate: 10 GS/s
Bandwidth limiter: 20 MHz, selectable
Enhanced vertical resolution: Hardware resolution + 4 bits
Input ranges: ±10 mV to ±20 V full scale, in 11 ranges
Input sensitivity: 2 mV/div to 4 V/div (10 vertical divisions)
Input coupling: AC / DC
Input characteristics: 1 MΩ ± 1% || 14 ±1 pF
Analog offset range (vertical position adjust):
±250 mV (10, 20, 50, 100, 200 mV ranges),
±2.5 V (500 mV, 1 V, 2 V ranges),
±20 V (5, 10, 20 V ranges)
Analog offset control accuracy: ±0.5% of offset setting, additional to basic DC offset accuracy
Overvoltage protection: ±100 V (DC + AC peak)
USB connection: USB 2.0, USB 3.0
External DC power supply
Voltage (V): 5 V
Current (A): 1.6 A pk
Power (W): 8 W (@5 V)
