Color: Green, Yellow
Pitch: 2.5 mm
Width: 5.2 mm
Height: 47.5 mm
Length: 57.8 mm
Unit Weight: 13.424 g
REACH - SVHC: Details
Current Rating: 400 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 600 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 26 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 26 AWG to 12 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
