Color: Gray
Width: 5.2 mm
Height: 49.9 mm
Length: 87.8 mm
Unit Weight: 13.130 g
Current Rating: 17.5 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 500 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 24 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 24 AWG to 16 AWG
Connection Method: Plug
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
