Color: Gray
Width: 32 mm
Height: 74.6 mm
Length: 90.5 mm
Unit Weight: 222.230 g
Current Rating: 269 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 1 kV
Wire Gauge Max: 250 kcmil
Wire Gauge Min: 10 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 10 AWG to 250 kcmil
Connection Method: Bolt
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
