Color: Black
Pitch: 6.3 mm
Width: 10.2 mm
Height: 60.5 mm
Length: 79 mm
Unit Weight: 34.132 g
Current Rating: 10 A
Mounting Style: DIN Rail
Voltage Rating: 500 V
Wire Gauge Max: 6 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 20 AWG to 6 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-2
Number of Positions: 1 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
