Color: Gray
Width: 10.2 mm
Height: 78 mm
Length: 77.5 mm
Unit Weight: 44.254 g
Current Rating: 57 A
Mounting Style: DIN Rail (NS 32, NS 35/7.5, NS 35/15)
Voltage Rating: 500 V
Wire Gauge Max: 6 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 20 AWG to 6 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
