Color: Orange
Width: 5.2 mm
Height: 21.7 mm
Length: 28.6 mm
Unit Weight: 3.330 g
Current Rating: 24 A
Mounting Style: Direct Mounting with Flange
Number of Rows: 1 Row
Voltage Rating: 450 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 26 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 26 AWG to 12 AWG
Connection Method: Push-In
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
