PCE VS10 Vibration Sensor (0,1~ 1000 m/s²)

Specification

Measuring range:0.1 ... 1000 m/s² acceleration

Frequency dependent velocity

Monitoring values:

Peak value of vibration acceleration or vibration velocity

RMS value of vibration acceleration or vibration velocity

High pass filter:0.1 / 2 / 5 / 10 / 20 / 50 / 100 / 200 / 500 / 1000 Hz acceleration

2 / 5 / 10 / 20 / 50 Hz velocity

Low pass filter:0.1 / 0.2 / 0.5 / 1 / 2 / 5 / 10 kHz acceleration

1 kHz velocity

Relay output:

PhotoMOS relay

SPST

Max. 60 V / 0.5 A (AC/DC)

Open/close programmable

Connection via screw terminals

Teach-in function: Button for measuring the switching threshold

Warning / alarm: Green and red LEDs

Alarm delay / hold time: 0 ... 99 s / 0 ... 9 s

Interfaces:

USB 2.0 full speed for parameterization and measurement

CDC mode / virtual COM port

Micro USB port inside

External USB port: No

Power supply voltage:

5 ... 30 V DC

5 V DC USB

< 100 mA screw terminals

Ingress protection:IP67 rating

Operating temp. range:-40 ... +80 °C / -40 ... +176 °F

Approx. weight:160 g / 0.36 lb

Approx. dimensions:

50 mm / 1.97" Ø

52 mm / 2.05" height

Mounting:

M8 thread pin

8 mm / ≈ 0.32" length

25 mm / ≈ 0.99" Ø coupling surface

Delivery contents

1 x PCE-VS10 vibration analyzer sensor switch

1 x USB cable

1 x PC-compatible software

1 x user manual
