PCE USC 30 Coating Thickness Gauge

Specifications

Frequency range: 0.01 ... 16000 kHz

Probe voltage supply: 0, 5, 1, 2, 4, 6 V

Signal phase shift: 0 ... 360 °

Sampling frequency: 0 ... 10 kHz

Duration of signal superimposition: 0 / 0.5 / 1/2/3/4 seconds

Alarm: Circular, horizontal line, circle sector, cut off

Display: Full-color display (TFT)

Display size: 4.3 "(diagonal)

Display resolution: 800 x 480 pixels

Amplification adjustment: 0 ... 100 dB

Filters: Low-pass (1 ... 4000 Hz), high-pass (1 ... 4000 Hz), band, differential, average

Average interval between measurement errors: 4000 hours

Power supply: 12 V battery

Battery capacity: 4500 mAh

Continuous runtime per battery charge: Approx. 8 hours

Operating temperature: -20 ... +45 ° C

Weight: Approx. 0.9 kg

Dimensions: 230 x 135 x 98 mm

Dilivery Contents

1 x PCE-USC 30 coating thickness gauge / meter / material tester

1 x eddy current probe

1 x calibration standard

1 x probe cable

1 x computer connection cable

1 x conductivity probe

1 x battery

1 x battery charger

1 x carrying case

1 x user manual
