Handheld measuring range: -32 ... +32 m/s
Resolution: 0.0001 m/s
Accuracy for DN ≥ 50 mm:
for DN < 50 mm:
±3.5 % of measured value
±1.0 % of measured value
Reproducibility±1.0 % of measured value
Media
All liquids with an impurity
<5% and a flow >0.03 m³/h
Flow unitsCubic meter [m³]
Liter [l]
Gallon (USA) [gal]
Imperial gallon (UK) [igl]
Million USA gallon [mgl]
Cubic foot [cf]
Barrel (USA) [bal]
Imperial barrel (UK) [ib]
Oil barrel [ob]
Time settingsper day [/d]
per hour [/h]
per minute [/m]
and per second [/s]
Data logger1800 measurements
InterfaceUSB (for online measurement and reading of the internal memory)
ProtectionIP 52
Power supply3 x AA NiMH rechargeable battery / 2100 mAh
(at full charge 12h running time) 100 … 240 V AC 50/60 Hz
Dimensions214 x 104 x 40 mm / 8.4 x 4.1 x 1.5"
Weight450 g / 15 oz
Sensornominal width DN 15 … 100, 20 … 108 mm / approx. 3/4 ... 4"
Temperature of liquid-30 … 160 °C / -22 ... 320 °F
Dimensions50 x 45 x 45 mm / 1.9 x 1.7 x 1.7"
Weight260 g / 9oz
Technical data evaluation software
- Units of power W, kW, MW, J/h, kJ/h, MJ/h, Btu/h, kBtu/h, MBtu/h
- Units of energy J, kJ, MJ, Wh, kWh, MWh, Btu, kBtu, MBtu
- Graphical representation of flow, flow temperature,
return temperature, heat output and heat quantity
- Tabular representation of flow, flow temperature,
return temperature, heat output and heat quantity
- Mobile and stationary measurement mode
- Real-time data logger with unlimited runtime (only limited by PC memory capacity)
- Data export function
- User-guided software operation with step-by-step instructions for
device and software configuration
Technical Data Temperature Datalogger PCE-T 330
Measuring range thermocouple Type K -200 … +1370 °C / -328 ... 2498 °F
Resolution0.01 °C
Accuracy*±(0.3 % of rdg. +0.40) °C*
Measuring range thermocouple Type T--200 … +400 °C / -328 ... 752 °F
Resolution/td>00.01 °C
Accuracy*/td>±±(0.3 % of rdg. +0.40) °C*
Measuring range thermocouple Type J--200 … +1200 °C / -328 ... 2192 °F
Resolution/td>00.01 °C
Accuracy*/td>±±(0.3 % of rdg. +0.40) °C*
Measuring rate2/s
Operating temperature-10 … +50 °C / 14 ... 122 °F
Storage temperature-20 … +60 °C (without batteries) / -4 ... 140 °F
Power supply3 x AAA batteries / 1.2 V battery
Battery lifeca. 190 h
(without backlight, battery capacity 1200 mAh,
ambient temperature 25 °C)
Protection classIP52 (with protective cover and connected sensor)
Norm/ certificationCE/EMC ROHS
