PCE PTR 200N Dynamometer (0~200 N/0~45 lb)

Specification

Measuring range: 0 ... 200 N / 0 ... 45 lbs

Calibration:0.1 N / 0.02 lbs

Pressure calibration:1 Mpa

Load cell:Integrated load cell with M6 connection

Measuring range:1 ... 100% of the full scale

Measurement accuracy:± 0.5%

Units:n, kg, lb

Display:LCD

Operating temperatur:10 ... 30°C / 50 ... 86°F

Relative fencing:15 ... 80% relative humidity

Working conditions:The device must not be located near sources of vibration or corrosive substances

Weight:1 kg / 2.2 lbs

Delivery contents

1 x Dynamometer PCE-PTR 200N

1 x Instructions for the penetrometer

1 x Penetration tip of Ø 6 mm / 0.2 in

1 x Penetration tip of Ø 8 mm / 0.3 in

1 x Penetration tip of Ø 11 mm / 0.4 in

2 x Locking rings

1 x Conversion table

1 x Evaluation software

1 x USB cable

1 x Charging adapter

1 x Carrying case for the dynamometer
