Light
Measurement range up to: 5 ... 200000 lx
Resolution: 0.1 lx
Accuracy: ±0.1 lx
General technical data
Display type: LCD touchscreen
Display size: 5 Inch
Display resolution: 480 x 854
Storage medium: Internal memory
Storage capacity: 8 GB
Memory capacity (additional information): approx. 5000 data records
Interface: USB, BLE switch
Operating time: 20 h
Automatic power-off from...to: 2 ... 60 min.
Automatic power-off can be deactivated: Yes
Reproducibility: ±0.5 nm
Colour spaces: CIE1931, CIE1960, CIE1976, SDCM, CRI1, CRI2, TM30 (Distribution of Fidelity), TM30 (Change Distribution), TM30 (Rg/Rf)
Wavelength range: 380 ... 780 Nm
Light parameters: CCT (K), Illuminance (lx), Coordinate-x, y, Coordinate-u, v, Coordinate-u', v', PeakWave (nm), CentralWave (nm), DominantWave (nm), CentroidWave (nm), HalfWidth (nm), Darksignal, Peak signal, Purity (%), IntegTime (ms), SDCM, Ra, Ravg, R1-R5, R6-R10, R11-R15, duv, R-ratio (%), G-ratio (%), B-ratio (%), Irradiance (W/m²), Candela (fc), S/P, CIE1931-X, CIE1931-Y, CIE1931-Z, CQS, Rg, Rf, Transmittance (%)
Menu language: English, Chinese, English (GB)
Protection class (device): IP56
Power supply: 100 ... 240V AC | 50/60 Hz
Connector type: Euro plug
Capacity: 4000 mAh
Operating conditions: -10 ... 40 °C , 70 % RH
Storage conditions: -20 ... 45 °C , 70 % RH
Dimensions ( L x W x H ): 160 x 82 x 22 mm
Weight: 390 g
