Specification
Measurement range (selectable):
-20 ... 100°C / -4 ... 212°F
0 ... 250°C / 32 ... 482°F
0 ... 1000°C / 32 ... 1832°F
Accuracy:± 1% of measured value
Emissivity:0.2 ... 1.0 adjustable
Distance-to-target ratio:20:1
Spectral range:8 ... 14 µm
Power supply:24V DC
Output:4 ... 20-mA
Impedance:900 ohms
Interface (selectable):Modbus RTU
Storage interval:1/s ... 1/day
Micro SD card:Max. 2 GB (not included)
Data format:CSV
Alarm relay (selectable):Changeover relay 24V / 1 A DC
Dimensions display:96 x 64 x 36 mm / 3.8 x 2.5 x 1.4 in
Dimensions temperature sensor: Ø18 x 45 mm / .7 x 1.8 in
M16
Cable length:1 m / 3.3 ft
Weight:390 g / < 1 lb
Protection class:IP65
Ambient temperature:0 ... 180°C / 32 ... 356°F
Ambient humidity:Max. 95% RH
Delivery contents
1 x Infrared thermometer PCE-IR 54
1 x User manual
