- Rated Power (VA): 6000
- Coupling Mode: Direct
- Form: 1Ø/2Ø; 3Ø
- Output Voltage Max (1Ø/2Ø; 3Ø) (l-n/l-l): 135/270; 135/234
- Current (1Ø/2Ø; 3Ø) (Arms): 48/16; 16/Ø
- Frequency Range: 20~5000
- Input Power: 3Ø 47-63Hz
- Unit Height (In/mm/U): 14/356/8U
- Unit Weight (Lbs/Kg): 195 /88.6
- Output Frequency:
20~5,000 Hz Direct Coupled
45~5,000 Hz Transformer Coupled
- Line Regulation: 0.1% max for a ±10% line change
- Load Regulation:
Direct Coupled Ranges:
0.25% 15 to 400 Hz.,
0.50% 400 to 1,200 Hz.
- Output Distortion:
0.1% THDAVG 45 ~ 1,000 Hz
0.25% THDAVG 20 ~ 5,000 Hz
- Ripple and Noise: -72dB
- Response Time: 5 μsec typ
