Bandwidth: 200MHz
Sample Rate: 1GS/s (500MS/s for each channel)
Vertical Resolution (A/D)): 8 bits
Record length: 40M
Waveform Refresh Rate: 70,000 wfms/s
Horizontal Scale (s/div)): 1ns/div - 1000s/div, step by 1 - 2 - 5
Channel: 4
Display: 8" color LCD, 800 x 600 pixels display
Sample Rate / Relay Time Accuracy: ±2.5 ppm
Input Coupling: DC, AC, GND
Vertical Sensitivity: 1mV/div - 10V/div (at input)
Trigger Type: Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, RS232,
and CAN (optional)
Bus Decoding(optional): I2C, SPI, RS232, CAN
Trigger Mode: Auto, Normal, and Single
Vertical Range: ±2V(1mV/div～50mV/div)；±20V(100mV/div～1V/div)；±200V(2V/div～10V/div)
Waveform Math: +, -, *, /, FFT, Intg, Diff, Sqrt, and user defined function
Communication Interface: USB host, USB device, USB port for PictBridge, Trig Out (P/F), LAN, and VGA (optional)
Frequency Counter: available
Power Supply: 100V - 240V AC, 50/60Hz, CAT II
Fuse: 2A, T class, 250V
Battery (optional): 3.7V, 13200mA
Dimension (W x H x D): 340mmx177mmx90mm
Optional Module: VGA. WIF, AWG, DMM, MTS
Accessories: Power Cord, CD Rom, Quick Guide, USB Cable, Probe Adjust, Probe, Soft Bag (optional), Q9 (optional), Multimeter Lead(optional), Battery (optional), Capacitance Ext Module (optional)
