Bandwidth: 25MHz
Vertical Resolution (A/D): 8bits
Channel Number: 2
Sampling Rate: 100 MSa/s
Rise Time: ≤14 ns
Horizontal Scale (s/div): 5ns/div - 1000s/div, step by 1 - 2 - 5
Sampling Mode: sample, peak detect, average
Record Length: 1M
Input Coupling: DC, AC, ground
Input Impedance: 1 MΩ ± 2%, in parallel with 12 pF ± 5 pF
Max Input Voltage: 40 V (DC + AC Peak)
Channel Isolation: 100 : 1 @ 50Hz; 40 : 1 @ 10MHz
DC Gain Accuracy: ±3%
Vertical Sensitivity: 2 mV/div - 10 V/div, step by 1 - 2 - 5
Vertical Displacement: ± 2V (2 mV/div – 200 mV/div); ± 40V (500 mV/div – 10 V/div)
Trigger Type: edge, video, slope, pulse
Trigger Mode: auto, normal, single
Line/Field Frequency (in video trigger): supported standards: NTSC, PAL and SECAM broadcast systems
Automatic Measurement: Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Overshoot, Preshoot, Frequency, Period, Rise Time, Fall Time, Delay A→B, Delay A→B, +Width, -Width, +Duty, -Duty
Isolation: no isolation
Communication Interface: USB Device (Type C)
Power Source: DC 5V
Power Consumption: ≤ 5 W
Device Dimension: 190 × 118 × 120 mm (W × H × D)
Weight: ≈ 0.38 kg
