OWON SP3101 Programmable DC Power Supply (150W)

Channel: Single Channel Output

Total Output Power: 150W

Channel Output: 0 - 30V / 0 - 10A

Display: 4-inch color LCD display

Dimension: 117mm(L) × 194mm（H) × 295mm（D）

Weight: Approx. 3.0 kg

Interface: RS232

MEASUREMENT

Rated Output (0℃-40℃): 0 - 30V/ 10A

Load Regulation: ≤30mV/ ≤30mA

Power Resolution: ≤20mA/ ≤20mA

Setting Resolution: 10mV/ 1mA

Readback Resolution: 10mV/ 1mA

Value Resolution (within 12 months) (25℃±5℃): ≤0.1% + 20mV/ ≤0.05% + 10mA

Readback Accuracy Resolution (25℃±5℃): ≤0.1% + 20mV/ ≤0.1% + 10mA

Ripple/Noise (20Hz-20MHz): (Vp-p) ≤30mVp-p

(rms) ≤3mVrms

(rms）≤30mAp-p

Output Temperature coefficient (0℃-40℃): ≤0.3% + 10mV / ≤0.3% + 20mA

Readback Temperature Coefficient: ≤0.3% + 10mV / ≤0.3% + 20mA

Response Time: ≤1.0ms

Storage: 5 groups of data

Working Temperature: 0-40℃

Accessories:

Power Cord

Manual Fuse

RS232 to USB Module( optional )

Test Leads(optional)
