Specifications
Bandwidth: 100MHz
Sample rate(Real time): 1GS/s
Horizontal Scale(S/div) 2ns/div~100s/div, step by 1~2~5
Rise time (at input, typical) ≤3.5ns
Channels: Dual
Display 8" color LCD, TFT display , 800*600 pixels, 65535 colors
Input impedance 1MΩ±2%in parallel with 15pF±5pF
Channels Isolation 50Hz: 100 : 1, 10MHz: 40 : 1
Max. input voltage: 400V (PK-PK) DC + AC PK-PK
DC gain accuracy: ±3%
DC accuracy(Average) Average≥16:±(3% reading+0.05div) for ΔV
Probe attenuation factor: 1X，10X，100X，1000X
LF respond(AC, -3dB) ≥5Hz(at input, AC coupling, -3dB)
Record length Max.10M points for each channel
Sampling rate/relay time accuracy ±100ppm
Interpolation (sin x)/x
Interval(ΔT) accuracy (full bandwidth) Single: ±(1 interval time+100ppm×reading+0.6ns) Average>16:±(1 interval time+100ppm×reading+0.4ns)
Input coupling DC, AC , Ground
Vertical resolution (A/D) 8 bits resolution (2 Channels simultaneously)
Vertical sensitivity 2mV/div～10V/div(at input)
Trigger type Edge, Pulse, Video, Slope, Alternate
Trigger mode Auto, Normal, Single
Trigger level ±6 divisions from screen center
Acquisition modes Sample, Peak Detect and Average
Line/field frequency(Video) Support standard NTSCPAL and SECAM broadcast systems
Cursor measurement ΔV and ΔT between cursors
Waveform Math ＋, －, ×, ÷, FFT
Waveform storage 15 waveforms
Communication interface USB2.0, USB flash disk storage, LAN, Pass/Fail
Cymometer Available
Power supply 100V-240V AC, 50/60Hz, CATII
Power consumption <18W
Fuse 1A, T class, 250V
Included Accessories
1 - Probe
1 - Power cord
1 - Probe adjust pen
1 - USB data cable
1 - CD-Rom
1 - User Manual
includes a DB-15 VGA port for external monitor and ALSO a LAN port at no additional cost!
