Bandwidth : 60Mhz
Sample Rate (real time) : 500Mhz
Channel : 2 + 1 (external)
Horizontal Scale (s/div) : 5ns/div - 100s/div,
Hiện thị : 8 inch color LCD, TFT display , 800 × 600 pixels, 65535 colors
Max Input Voltage : 400V (PK - PK) (DC+AC, PK - PK)
|
Model |
SDS5032E |
SDS6062E |
SDS7072E |
SDS7102E |
SDS7122E |
|
|
Bandwidth |
30MHz |
60MHz |
70MHz |
100MHz |
125MHz |
|
|
Sample Rate (real time) |
250MS/s |
500MS/s |
1GS/s |
|||
|
Horizontal Scale (s/div) |
4ns/div～100s/div, |
5ns/div - 100s/div, |
2ns/div - 100s/div, |
|||
|
Rise Time (at input, typical) |
≤11ns |
|||||
|
Channel |
2 + 1 (external) |
|||||
|
Display |
8" color LCD, TFT display , 800 × 600 pixels, 65535 colors |
|||||
|
Input Impedance |
1MΩ ± 2%, in parallel with 15pF±5pF |
|||||
|
Channel Isolation |
50Hz : 100 : 1, 10MHz : 40 : 1 |
|||||
|
Max Input Voltage |
400V (PK - PK) (DC+AC, PK - PK) |
|||||
|
DC Gain Accuracy |
±3% |
|||||
|
Record Length |
10K |
100K (optional 10M) |
||||
|
DC Accuracy (average) |
Average≥16：±(3% reading + 0.05 div) for △V |
|||||
|
Probe Attenuation Factor |
1X, 10X, 100X, 1000X |
|||||
|
LF Respond (AC, -3dB) |
≥5Hz (at input, AC coupling, -3dB) |
|||||
|
Sample Rate / Relay Time Accuracy |
±100ppm |
|||||
|
Interpolation |
sin (x) / x |
|||||
|
Interval (△T) Accuracy (full bandwidth) |
Single : ±(1 interval time + 100ppm × reading + 0.6ns), Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns) |
|||||
|
Input Coupling |
DC, AC , and GND |
|||||
|
Vertical Resolution (A/D) |
8 bits resolution (2 Channels simultaneously) |
|||||
|
Vertical Sensitivity |
5mV/div～10V/div (at input) |
2mV/div～10V/div (at input) |
||||
|
Trigger Type |
Edge, Pulse, Video, Slope |
Edge, Pulse, Video, Slope, Alternate |
||||
|
Trigger Mode |
Auto, Normal, Single |
|||||
|
Trigger Level |
±6 divisions from screen center |
|||||
|
Line / Field Frequency (video) |
NTSC, PAL, and SECAM standard |
|||||
|
Cursor Measurement |
△V, and △T between cursors |
|||||
|
Automatic Measurement |
Vpp, Vavg, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot, |
|||||
|
Waveform Math |
＋, －, ×, ÷, FFT |
|||||
|
Waveform Storage |
15 waveforms |
|||||
|
Lissajous Figure |
Bandwidth |
Full bandwidth |
||||
|
Phase Difference |
±3 degrees |
|||||
|
Communication Interface |
USB, USB flash disk storage, Pass / Fail, LAN, VGA (optional） |
|||||
|
Cymometer |
available |
|||||
|
Power Supply |
100V - 240V AC, 50/60Hz, CAT Ⅱ |
|||||
|
Power Consumption |
＜18W |
|||||
|
Fuse |
2A, T class, 250V |
|||||
|
Battery |
not supported |
|||||
|
Dimension (W×H×D) |
348 × 170 × 78 (mm) |
|||||
|
Weight (without package) |
1.50 kg |
|||||
