Frequency Range: 9 kHz to 1.500009 GHz
Frequency Resolution: 1 Hz
Frequency Span:
Span Range: 0 Hz, 100 Hz to max frequency of instrument
Span Uncertainty: ± span / (sweep points-1)
SSB Phase Noise (20℃ to 30℃,fc=1 GHz, RBW=1 kHz,VBW=1 kHz)
Carrier Offset:
10 kHz: < -80 dBc/Hz (Typical)
100 kHz: < -100 dBc/Hz (Typical)
1 MHz: < -107 dBc/Hz (Typical)
Bandwidth:
Resolution Bandwidth: 10 Hz to 500 kHz (1-10 steps by sequence), 1 MHz, 3 MHz
RBW Accuracy: < 5%, typical (RBW ≤ 1 MHz)
Resolutio Filter Shape Factor (60 dB : 3 dB): <5: 1 typical (digital and close to Gaussian shape)
Video Bandwidth (VBW): 10 Hz to 3 MHz
Amplitude and level:
Amplitude measurement range: DANL to +20 dBm, 1 MHz to 3.6 GHz, Preamp Off
Reference Level: -80 dBm to +30 dBm, 0.1dBm by step
Preamp: 20 dB, nominal, 9 kHz to 3.6 GHz
Input Attenuator Range: 0 to 40 dB, in 1 dB step
Display Average Noise Level (Input Attenuation= 0 dB, Sample Detector ,Trace Average ≥20, 20℃ to 30℃,Input Impedance=50 Ω ,RBW normalizes to 1Hz)
Preamp Off:
1 MHz to 1 GHz: -140 dBm (Typical), <-130 dBm
1 GHz to 1.5 GHz
Preamp On:
1 MHz to 1 GHz: -160 dBm (Typical), <-150 dBm
1 GHz to 1.5 GHz
Frequency response (20℃ to 30℃, 30% to 70% relative humidity, input attenuation=20 dB, reference frequency=50 MHz)
Preamp Off (fc≥100K): ±0.8 dB;±0.4 dB (Typical)
Preamp On (fc≥1 MHz): ±0.9 dB;±0.5 dB (Typical)
Difference and Accuracy:
Absolute Amplitude Accuracy:
20℃ to 30℃, fc=50 MHz, Span=200 kHz, RBW=10 kHz, VBW=10 kHz, peak detector, 10 dB RF attenuation,95% confidence level
Preamp Off ±0.4 dB, input signal level -20 dBm
Preamp On ±0.5 dB, input signal level -40 dBm
Tracking Source Output, signal generator:
Frequency Range: 100 kHz to 1.5 GHz (Tracking Source Output)
Output power level range: -30 dBm to 0 dBm
Output power level resolution: 1 dB
Output flatness: ± 3 dB
USB
USB Host
Connector: A Plug
Protocol: USB 2.0 (Host End)
USB Device:
Connector: Micro USB
Protocol: 2.0 Version
Display:
Type: TFT LCD
Resolution: 1024*768
Size: 8 inches
Color: 65536
Remote Control:
USB: USB TMC
LAN: 10/100 Base, RJ-45
Appearance:
Dimensions: 265 mm (W) × 190 mm (H) × 58 mm (D)
Weight: Approx. 2.5 kg (without package)
