Oscilloscope Specifications:
Bandwidth: 40MHz
Channel: 1
Sampling rate: 250MSa/s
Sampling method: Sampling, peak detection
Record length: 4K or 8K
Display: 3.5-inch LCD
Waveform refresh rate: 10,000wfms/s
Input coupling: DC, AC, GND
Probe attenuation: 1X, 10X, 100X, 1000X, 10000X
Maximum input voltage: 400V (DC+AC, PK-PK)
Sweep speed range (s/div): 5ns/div-1000s/div, Step by1-2-5
Sensitivity (Volt/div) range: 10mV/div-10V/div
Trigger Type: Edge
Automatic measurement: Period, Frequency, Mean, PK-PK, Max, Min, Amplitude, RMS
Cursor measurement: △V, △T
Interface: USB Type-C
Multimeter Specification:
Digital display: 24000 readings
Measurement type: Voltage, Current, Resistance, Capacitance, Continuity,Diode
Maximum input voltage: AC:750V DC 1000V
Maximum input current: AC:10A DC:10A
Diode test: 0-2V
Auto range: ✓
Continuity: <50Ω
TRMS: ✓
[Waveform Generator] Specification:
Output Frequency:
Sine: 10Hz-100kHz, Step by1-2-5
Square : 10Hz-100kHz, Step by1-2-5
Ramp: 10Hz-100kHz, Step by1-2-5
Pulse: 10Hz-10kHz, Step by1-2-5
Amplitude: 1Vpp or 2.5Vpp
