Bandwidth (-3 dB): 200MHz
Channel: 4+EXT
Sample Rate: 2.5 GSa/s (single channel) 1.25 GSa/s (dual channel) 1.25 GSa/s (full channel)
Acquire mode: Sample, Peak, High Res, Average
Waveform Refresh Rate: Max 500,000 wfms/s
Scanning speed (S/div): 500μV/div - 10 V/div
DC Gain Accuracy: 4%(≤1mV)3%(≥2 mV)
Record Length: 100M
Vertical Resolution: 8bits
Sampling rate range: 0.05 S/s～2.5 GS/s
Relay time accuracy: ±1 ppm(typical)
Input Impedance: 1 MΩ ± 2%, parallel with 15pF ± 5pF, 50Ω ± 2%
Probe attenuation coefficient: 1μX-1MX, step by 1-2-5, support custom
Trigger type: Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth, Logic, RS232/UART, I2C, SPI CAN, LIN
Bus Decoding (optional): UART, I2C, SPI, CAN, LIN
Auto measurement: Period, Frequency, +Width, -Width, Rise Time, Fall Time, Scr Duty, +Duty,-Duty, Vavg, Vpp, VRMS, Overshoot, Vmax, Vmin, Vtop, CycRms, Vbase, Vamp, Preshoot, Std Dev, +Pulse Cnt, -Pulse Cnt, Rise Cnt, Fall Cnt, Area, Cyc Area,Delay(-),Delay(-), Phase(-), Phase(-), FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Waveform Math: +, -, *, /, Intg, Diff, Sqrt, Function operation (Lg / Ln / Exp / Abs / Sine / Cosine / Tan), FFT, FFT rms, User Defined, digital filter (low pass, high pass, band pass, band reject)
Frequency counter: 6-digit frequency counter； Maximum frequency: maximum analog bandwidth of oscilloscope
Voltmeter: Support DC, AC+DCrms, ACrms；Resolution: 4 digits (ACV/DCV)
Arb Waveform Generator (optioanl) Specification:
Max frequency output: 50MHz Dual
Vertical resolution: 14 bits
Sample rate: 160 MSa/s
Standard waveform: Sine, Square, Ramp, Pulse, Noise
Arbitrary waveform: Exponential Rise/Fall, Sin(x)/x, Step Wave, and others total 28 built-in waveforms
Arbitrary waveform frequency: 1 μHz - 10 MHz
Arbitrary waveform length: 2-16K points
Amplitude: 2mVpp - 10Vpp (high impedance), 1mVpp - 5Vpp (50 Ω)
Modulation: AM, FM, PM, FSK, Sweep and Burst
Other:
Communication Interface: HDMI, USB device x1, USB Host x3, Trig Out (P/F), Type-C power supply, LAN
Display: 10.1 inch (1024×600), LCD
Power: 100V – 240 VACRMS, 50/60 Hz, CAT Ⅱ
Dimension (WxHxD): 325mm x 209mm x 111.5mm
Weight (without package): ≈3.2kg
