Table Travel (X DM/SM): 1200 mm
Table Travel (Y): 700 mm
Servo Travel (Z): 500 mm
Max. Workpiece Dimensions (WxD): 1860 x 1120 mm
Max. Filling Height of Dielectric Tank: 460 mm
Distance Between Chuck to Table: 395 - 895 mm
Max. Workpiece Weight: 5000 kg
Max. Electrode Weight: 400 kg
Table Size (WxD): 1350 x 820 mm
Machine Weight: 6500 kg
Generator
Max. Working Current:120A
Overall Power Consumption:12KVA
Weight: 380kg
Dielectric
Tank Capacity:1875 L
Filter Density:20μm
Filter Elements: 6 pcs
