Absorber Type: BF
Aperture: Ø12mm
Spectral Range: 0.15-3, 10.6µm
Energy Range: 7µJ-10mJ
Maximum Frequency: 250Hz
Dimensions: Ø62 W x 21 D (mm)
Max Pulse Energy: 10mJ
Max Average Power Density: 50W/cm²
Max Pulse Width: 3ms
Damage Threshold (for <100ns): 0.8J/cm²
Damage Threshold (for 2ms): 10J/cm²
Max Average Power: 3W
Compliance: CE, UKCA, China RoHS
