Fall Time: 9 ns
Rise Time: 20 ns
Technology: SiC
Unit Weight: 4.675 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 220 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 468 W
Vgs - Gate-Source Voltage: - 15 V, + 25 V
Typical Turn-On Delay Time: 22 ns
Typical Turn-Off Delay Time: 42 ns
Id - Continuous Drain Current: 98 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 34 S
Rds On - Drain-Source Resistance: 28 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 4.3 V
