onsemi NCV8705MW30TCG Linear 500 MA ULTRA-LOW N OISE L

Output Type: Fixed

Qualification: AEC-Q101

Mounting Style: SMD/SMT

Output Current: 500 mA

Output Voltage: 3 V

Dropout Voltage: 230 mV

Line Regulation: 750 uV/V

Load Regulation: 12 uV/mA

Number of Outputs: 1 Output

Quiescent Current: 13 uA

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.5 V

Dropout Voltage - Max: 350 mV

Voltage Regulation Accuracy: 2 %

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

PSRR / Ripple Rejection - Typ: 71 dB
