Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 158.147 mg
Amplifier Type: Low Power Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 150 mV/us
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Ib - Input Bias Current: 400 pA
Operating Supply Current: 21 uA
Ios - Input Offset Current: 50 pA
Output Current per Channel: 11 mA
Vos - Input Offset Voltage: 6 uV
GBP - Gain Bandwidth Product: 270 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 62 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 106 dB
