OmniOn Power (Formerly ABB Power Conversion) ATH010A0X3-SRZ Non-Isolated / PoL 2.4-5.5Vdc Input 10A 0.75-3.63Vdc Output

Width: 13.46 mm (0.53 in)

Height: 8.28 mm (0.326 in)

Length: 33 mm (1.299 in)

Industry: Industrial

Output Type: Programmable

Unit Weight: 27.358 g

Output Power: 22 W

Mounting Style: SMD/SMT

Number of Outputs: 1 Output

Moisture Sensitive: Yes

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.4 V

Input Voltage, Nominal: 5 V

Output Current-Channel 1: 10 A

Output Voltage-Channel 1: 750 mV to 3.63 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
