Voltage Source
Output voltage:± 100 mVpeak to ± 200 Vpeak
Max. output current: 50 mApeak
Frequency Domain Spectroscopy (FDS)
Measurement current: max. ± 50 mApeak
Frequency range: 5 μHz to 5 kHz
Time Domain Current Measurement (PDC)
Measurement current: max. 10 mA
Frequency range: 20 µHz to 99 mHz
Input resistance: 2 kΩ
Combined Mode (FDS and PDC)
Frequency range: 20 μHz to 5 kHz
Time reduction:Up to 75 % in comparison to exclusive FDS measurements
Capacitance, Dissipation Factor and Impedance
Tanδ range: > 3x10-4
Capacitance range: 10 pF to 100 μF
Impedance range: 100 Ω to 20 TΩ
Dimensions (w x h x d): 260 x 50 x 256 mm (10.25 x 2 x 10.5 inch)
Weight: 2.3 kg (5 Ib)
