Height: 1.9 cm
Weight: 30 g
Accuracy: ± 0.1 %
Diameter: 4.45 cm
RTD Type: Pt100
Bandwidth: 3 dB @ 3Hz
Isolation: Non-Isolated
Linearity: ±0.1%
Hysteresis: ±0.1%
Input Type: RTD
Calibration: Trimpot/Switch
Sensor Type: Transmitter
Probe Length: 0 cm
Accuracy Note: ±0.1% FS (includes effects of linearity, hysteresis and repeatability)
Repeatability: ±0.1%
Setup Controls: Trimpot/Switch
Supply Voltage: 9 to 35 Vdc
Sheath Material: N/A
Electrical Output: 4 to 20 mA
Supply Power Note: 9 to 35 Vdc; 24 Vdc recommended
Supply Power Type: DC
Thermocouple Type: N/A
Input Control Signal: N/A
Loop Resistance, Max: (Vs-8.5V)/0.02A
Electrical Connection: Screw Terminal
Wiring/Connector Table: 2- or 3-Wire
Temperature Coefficient: 0.00385 Ω/°C
Temperature Input Range: 0 to 260 °C
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -65 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -25 °C
Zero Setting Adjustable Range: ±25% mV span centered around 0 mV (or °C) RTD models ±40°F
