Accuracy: ± 0.2 °C (± 0.36 °F)
Probe Length: 6 in
probe-length: 6 in
Accuracy Note: ± 0.2°C (0 to 70ºC)
Response Time: 14 sec
Probe Diameter: 0.25 in
Sheath Material: 316L Stainless Steel
Enclosure Ratings: IP67
Operating Current: 12 µA
Thermocouple Type: N/A
Nominal Resistance: 2252 Ω
Response Time Note: Approximately 7 seconds (50%), 8 seconds (63.2%), 14 seconds (90%) in water flowing at 0.91 m (3') per second
Color Code Standard: ANSI
Electrical Connection: M12 4 pin Male
Insulation Resistance: 100 MΩ
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Temperature Sensor Type: Thermistor
Process Temperature, Max: 200 °C
Process Temperature, Min: -50 °C
Connector Temperature, Max: 200 °C
Connector Temperature, Min: -50 °C
Insulation Resistance Note: 100 MΩ minimum at 100 Vdc at ambient temperature
Nominal Resistance/Curve Note: Resistance at 25°C
