Weight: 48 oz
Cv Factor: 0.005 gal/min
Materials: 316 Stainless Steel, FEP, 303 Stainless Steel, 302 Stainless Steel, 430 Stainless Steel
Coil Power: 24 Vdc/22 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Direct Acting
Orifice Size: N/A
Valve Position: Normally Open
Enclosure Ratings: NEMA Type 4, NEMA Type 7
Materials, Wetted: 303 Stainless Steel, 316 Stainless Steel, 430 Stainless Steel, FEP
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Electrical Connection: 1/2 NPT female Conduit with Wire Leads
Operating Pressure, Max: 5000 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 204 °C
Process Temperature, Min: -212 °C
Electrical Connection Note: 1/2 NPT, 457 mm (18") leads
