Mounting: Any (preferably with solenoid system upright)
Cv Factor: 2.8 gal/min
Materials: Brass, Nitrile Rubber, Stainless Steel 300, Stainless Steel 400, Copper
Coil Power: 8 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Direct Lift
Cycling Rate: 1000 cpm
Orifice Size: 5/8 in
Valve Position: Normally Closed
Enclosure Ratings: NEMA Type 4
Materials, Wetted: Brass, Buna-N (NBR), Copper, PA, Stainless Steel
Voltage Tolerance: ±10%
Open Response Time: 100 to 1000 ms
Close Response Time: 700 to 4000 ms
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Coil Molding Material: Black Polyester (Class F): SV8COIL-115AC, SV8COIL, 24AC/60HZ, SV8COIL-220AC Black Polyamide (Class F): SV8COIL-12DC, SV8COIL-24DC, all 12 Watt coils Black Polyphenylensulphide (Class H): SV8COIL-115/60HZ Black Epoxy Resin (Class H): All 14 Watt coils
Operating Pressure Note: AC 200 psi, DC 35 psi
Operating Pressure, Max: 200 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 90 °C
Process Temperature, Min: -10 °C
