Mounting: Pipe mounting, any direction
Cv Factor: 0.20 , 1.1 gal/min
Materials: Brass, Nitrile Rubber
Coil Power: 10 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Pilot Operated
Orifice Size: 3/32 in, 1/4 in
Supply Voltage: 120 Vac
Valve Position: Normally Closed
Static Pressure: 5 times max psid
Enclosure Ratings: IP65, NEMA Type 4
Materials, Wetted: Brass, Buna-N (NBR), Copper, Stainless Steel
Supply Power Note: 10 W, 120 Vac coils, 50 to 60 Hz
Open Response Time: 15 ms
Close Response Time: 45 ms
Media Compatibility: Air
Additional Features 1: Quick Exhaust
Operating Pressure, Max: 100 psi
Operating Pressure, Min: 2 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 85 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: -9 °C
