Length: 67 mm
Weight: 35 g
Accuracy: ± 4 °C (± 7.2 °F)
Diameter: 12 mm
Software: Compatible with OEG and SYNC configuration software
Approvals: CE, UKCA
Vibration: 10 Gs from 10 Hz to 500 Hz
Accuracy Note: Temperature Accuracy @ Ambient of 0 to 50°C(32 to 122°F): 1°C (1.8°F) or 1% of reading, whichever is greater Accuracy Over Entire Ambient Operating Range: 4°C (7.2°F) or 3% of reading, whichever is greater
Configuration: Configurable via SYNC configuration software
Field of view: 10:1
Number of I/O: 2
Repeatability: Temperature: 1°C
Thread Length: 33.5 mm
Supply Voltage: 3.3 Vdc
Emissivity, Max: 0.01 to 1.00
Thread Diameter: 12 mm
Measurement Type: Temperature
Enclosure Ratings: IP67, NEMA Type 6
Relative Humidity: 0 to 95% RH
Supply Power Type: DC
Enclosure Material: Stainless Steel
Number of Channels: 2
Repeatability Note: Temperature: 1°C (1.8°F) or 1% of reading
Spectral Response, Max: 14 µm
Spectral Response, Min: 5.5 µm
Process Connection Type: Internal
Process Temperature, Max: 380 °C
Process Temperature, Min: -70 °C
Temperature Response Time: 1 sec
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
