Shock: 50 g, 11 ms half-sine
Weight: 200 g
Accuracy: ± 0.08 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: 5-2000-5 Hz, 30 minute cycle,Curve L, Mil-Spec 810 figure 514-2-2, vertical and horizontal axis
Compliance: RoHS 2
Cable Length: 2 m
Accuracy Note: (CombinedLinearity,Hysteresis and Repeatability):± 0.08% BSL maximum Compound ranges calibrated only in positive direction
Output Signal: Digital
Pressure Type: Vacuum
Pressure, Max: 1 bar
Pressure, Min: 0 bar
Response Time: <1 ms
Accuracy Class: < 0.1%
Stability Note: Long Term Stability (1-Year): ± 0.1% FS typical
Pressure Cycles: 1 million, minimum
Electrical Output: USB
Materials, Wetted: 316L Stainless Steel
Additional Features 1: None
Electrical Connection: Cable
Insulation Resistance: 100 MΩ @ 50 Vdc
Electrical Output Note: None
Process Connection Size: 1/4 in
Process Connection Type: BSPP Male
