Accuracy: ± 0.25 %
Diameter: 28 mm
Stability: ± 0.2%
Fill Fluid: Silicon oil
Load Effect: ± 0.05% FS/kΩ
Cable Length: 595 in
Current Draw: 20.8 mA
Power Supply: 500 mW
Accuracy Note: 20°C ± 5°C (68°F ± 9°) PX633A1: 0.01% FS NLHR PX633A2: 0.25% FS NLHR PX633A5: 0.50% FS NLHR
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 250 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Supply Voltage: 10.5 to 55 Vdc
Thermal Effect: ± 0.2% FS/10K
Vibration Effect: IEC61298-3/GB/T 18271.3; 20g (5-2000HZ, max<± 3mm) <0.1% FS
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP68
Materials, Wetted: 316 Stainless Steel, FKM
Fits Cable Diameter: 7.3 to 7.7 mm
Loop Resistance, Max: <(U-10)/0.021 Ω, where U is supply voltage
Additional Features 1: Surge Protection
Electrical Connection: Submersible Cable
Transmission Distance: up to 1000 meters
Process Connection Type: Submersible
