Weight: 50 g
Accuracy: ± 1 %
Accuracy Note: 1.0% linearity and hysteresis combined; calibrated at 0%, 50%, 100%, 50%, 0%
Output Signal: Millivolt
Pressure Type: Gauge
Pressure, Max: 4000 psi
Pressure, Min: 0 psi
Accuracy Class: > 0.25%
Burst Pressure: 5x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 5 Vdc
Mating Connector: MIL-26482-I 10-6S
Bridge Resistance: 350 Ω
Electrical Output: 2 mV/V
Materials, Wetted: 17-4 Stainless Steel
Zero/Balance Error: ± 1% FS
Burst Pressure Note: 500% of capacity
Proof Pressure Note: 150% of capacity
Repeatability Error: 0.1% of FSO
Additional Features 1: None
Electrical Connection: MIL-26482-I 10-6P
electrical-connection: MIL-26482-I 10-6P
Electrical Output Note: Range @ 50 psi = 1 mV/V; range >100 psi: 2 mV/V
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -54 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Thermal Effect on Span error, Max: ± 0.02% FSO/°F
Thermal Effect on Zero error, Max: ± 0.02% FSO/°F , ± 0.01% FSO/°F
