Width: 48 mm
Height: 48 mm
Length: 85 mm
Memory: Non-volatile
Weight: 100 g
Inhibit: NPN or Dry Contact
Accuracy: ± 0.01 %
Frequency: 50/60 Hz
Impedance: 10 kΩ
Resolution: Settable for time values in hours/minutes/seconds ranges
Form factor: 1/16 DIN
Timer Range: Hours, minutes, seconds; hours, minutes; minutes, seconds
Control Mode: Repeat Cycle: Batch stop, batch continue and interval
Display Note: Dual-line, 4-digit, 7-segment LED, 8 mm H (0.31")
Display Type: Dual 4 Digit LED
Contact Rating: Relay: 2 SPDT (5 A), 15 ms max latency,Transistor:NPN Open Collector: 30 Vdc, 30 mA max opto isolated
Humidity Range: 5 to 95% RH, non-condensing
Supply Voltage: 90 to 240 Vac
Activation Time: 21 ms
Measurement Type: Time
Number of Relays: 2
Cutout Dimensions: 45 x 45 mm
Enclosure Ratings: IP65
Power Consumption: 10 VA
Supply Power Type: AC
Inputs Start and Reset: NPN or dry contact
Storage Temperature, Max: 90 °C
Storage Temperature, Min: -40 °C
Number of Timer Functions: 17
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
