Width: 4 in
Height: 1.5 in
Length: 1.25 in
Switch: Single
Weight: 8.5 oz
Cycling: < 20 cycles/min
Switch Note: SPDT, rated 0.25 A @ 120 Vac/175 Vdc
Switch Type: SPDT NO/NC, Selectable
Deadband Type: Fixed
Pressure Type: Differential
Pressure, Max: 25 psi
Pressure, Min: 2 psi
Repeatability: ± 4%
Control Output: SPDT Relay
Proof Pressure: Up to 9000 psi
Proof Pressure Note: Vacuum: to 6000 psig Differential Pressure: to 2000 psid Proof: 9000 psig
Electrical Connection: Pigtail Leads
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Operating Temperature Note: -54 to 107°C (-65 to 225°F); setpoint change of up to 2% of sensor capacity may be anticipated when switch is used below -23°C or above 52°C
Operating Temperature, Max: 107 °C
Operating Temperature, Min: -54 °C
