Shock: Setpoint repeats after 15 g, 10 ms duration
Width: 4.9 in
Height: 4 in
Length: 5.5 in
Switch: Dual
Weight: 7.5 lb
Approvals: UL, CE compliant
Materials: Aluminum, Epoxy, Brass
Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz
Sensor Type: Bellows
Switch Note: 2 or 3 SPDT; switches can be separated up to 100%, except models PSW-852A and PSW-852B: 30%; switches can be wired “normally open” or “normally closed”.
Switch Type: SPDT NO/NC, Selectable
Weight Note: Approx. 1.4 to 3.4 kg (3 to 7.5 lb) (varies with model)
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 80 inH₂O
Pressure, Min: 0 psi
Control Output: SPDT Relay
Proof Pressure: Up to 5 psi
Enclosure Ratings: NEMA Type 1
Materials, Wetted: Brass
Electrical Connection: Screw Terminal
Setpoint Repeatability: ± 2%
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Storage Temperature, Max: 71 °C
Storage Temperature, Min: -54 °C
Operating Temperature Note: -40 to 70°C (-40 to 160°F), except model PSW-852A: -40 to 70°C (0 to 160°F); set point typically shifts less than 1% of range for a 30°C (54°F) ambient temperature change
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -40 °C
Setpoint Repeatability Note: ± 2% of adjustable range, except model PSW-852E: ± 3% of adjustable range
