Shock: Setpoint repeats after 15 g, 10 ms duration
Width: 4.9 in
Height: 9 in
Length: 4.3 in
Switch: Single
Weight: 4 lb
Deadband: 4 to 45 psi
Approvals: UL listed; Class I, Division 1 and 2, Groups B, C and D; Class II, Groups E, F and G; Class III
Materials: 316L Stainless Steel, Aluminum, Epoxy, Stainless Steel
Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz
Sensor Type: Diaphragm
Switch Type: SPDT NO/NC, Selectable
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 500 psi
Pressure, Min: 20 psi
Repeatability: ± 1%
Control Output: SPDT Relay
Proof Pressure: Up to 2500 psi
Dial Graduation: Blind
Enclosure Ratings: IP66, NEMA Type 4X
Electrical Connection: Screw Terminal
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Process Temperature, Max: 204 °C
Process Temperature, Min: -57 °C
Operating Temperature, Max: 71 °C
Operating Temperature, Min: -50 °C
