Shock: Setpoint repeats after 15 g, 10 ms duration
Switch: Single
Weight: 2 lb
Deadband: 0.1 to 0.4 psi
Approvals: UL listed
Materials: Aluminum, Bronze
Vibration: Setpoint repeats after 2.5 g, 5 to 500 Hz
Sensor Type: Bellows
Switch Type: SPDT NO/NC, Selectable
Output Value: 15A @ 125/250/480 Vac
Deadband Type: Fixed
Pressure Type: Differential
Pressure, Max: 90 psi
Pressure, Min: 10 psi
Repeatability: ± 1%
Control Output: SPDT Relay
Proof Pressure: Up to 90 psi
Static Pressure: 30 inHg Vac to 200 psi
Electrical Connection: Screw Terminal
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 120 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 75 °C
Storage Temperature, Min: -55 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -40 °C
