Accuracy: Class A
Wire Gauge: 26 AWG
Cable Length: 1 m
Accuracy Note: Class A (± 0.15+.002*
Lead Material: Nickle Plated Copper
Sensor Length: 0.6 in
Number of Wires: 2
Sensing Element: Class “A” DIN Platinum Element
Sensor Diameter: 0.08 in
Housing Material: N/A
Nominal Resistance: 100 Ω
Long Term Stability: <0.04% after 1000hr
Recommended Current: N/A
Self Heating Effect: Water [v=0ms], E = 15 mW/K
Response Time, Water: 0.5 sec
Insulation Resistance: >50 MΩ @ 50 Vdc
Temperature Sensor Type: RTD
Process Temperature, Max: 350 °C
Process Temperature, Min: -200 °C
Insulation Resistance Note: Greater than 50 Megohms at 50 Vdc. at 25°C (77°F)
