Accuracy: Class A
RTD Type: 1000 Ω pt sensor
Probe Length: 2.5 in
Accuracy Note: IEC Class A ± 0.15°C (at 0°C)
Probe Diameter: 0.25 in
Number of Wires: 4
Sheath Material: 304 Stainless Steel
Mating Connector: MIL-26482-I 8-4S
Sensor Type Note: Pt1000 RTD (1000 Ω at 0°C)
Thermocouple Type: N/A
Nominal Resistance: 1000 Ω
Electrical Connection: MIL-26482-I 8-4P
Process Connection Size: 7/16 in
Process Connection Type: UNF Male
Temperature Sensor Type: RTD
Measurement Current, Max: 0.5 mA
Measurement Current, Min: 0 mA
Process Temperature, Max: 200 °C
Process Temperature, Min: -50 °C
