OMEGA PGF-25B-60 Liquid Filled and Leakproof Pressure Gauge (Gauge; 0~60psi; 1/4"NPT Male)

Pressure Type: Gauge

Pressure Range Units: psi

Pressure Range Min: 0

Pressure Range Max:60

Pressure Port Type: NPT Male

Pressure Port Size: 1/4"

Accuracy Value: ±3-2-3%

Accuracy Class: > 0.25%

Dial Size: 2.5"

Additional Features: Liquid filled, Rear Connection

Case: Stainless Steel

Wetted Parts: Brass/Bronze

Window: Polycarbonate with o-ring seal

Fill Fluid: Glycerine

Temperature: 66°C (150°F)

Fitting: ¼ NPT Brass

Accuracy: 3-2-3% (3% first 1/3 of scale, 2% middle 1/3 of scale, 3% last 1/3 of scale)

See more detail information in the Datasheet
